Mesa Mistura Dynacord CMS 600-3

Especificações Técnicas :

Channels 4 +2 + 2
MIC/Line-Mono 4
MIC/Line-Mono / USB-Stereo (Super Channel) 2
Line L-R / CD-IN-Stereo 2
Auxiliaries (AUX, MON) Pre/Post switchable, Pre
MIC GAIN (LINE -20 dB) +10 to +60 dB
TRIM LINE/CD (Stereo) -10 to +20 dB
THD, at 1 kHz, MBW = 80 kHz
MIC input to Master A L/R outputs, +16 dBu, typical < 0.005%
Frequency Response, -3 dB, ref. 1 kHz
Any input to any Mixer output 15 Hz to 70 kHz
Crosstalk, 1 kHz
Channel to Channel < -80 dB Mute & Standby switch attenuation > 100 dB
Fader & FX/AUX/MON-Send attenuation > 85 dB
CMRR, MIC input, 1 kHz > 80 dB
Input Sensitivity, all level controls in max. position
MIC -74 dBu (155 µV)
LINE (Mono) -54 dBu (1.55 mV)
LINE (Stereo) -34 dBu (15.5 mV)
CD (Stereo) -34 dBu (15.5 mV)
Maximum Level, mixing desk
MIC inputs +12 dBu
Mono Line inputs +31 dBu
Stereo Line inputs +30 dBu
All other inputs +22 dBu
All other outputs +22 dBu
Input Impedances
MIC 2 ㏀
CD In 10 ㏀
All other inputs > 15 ㏀
Output Impedances
Phones 47 Ω
All other outputs 75 Ω (unbalanced), 150 Ω (balanced)
Equivalent Input Noise, MIC input, A-weighted, 150 ohms -130 dBu
Noise, Channel inputs to Master A L/R outputs, A-weighted
Master fader down -100 dBu
Master fader 0 dB, Channel fader down -92 dBu
Master fader 0 dB, Channel fader 0 dB, Channel gain unity -82 dBu
Equalization
LO Shelving ±15 dB / 60 Hz
MID Peaking ±12 dB / 2.4 kHz
HI Shelving ±15 dB / 12 kHz
Master EQ 9-band (63, 125, 250, 500, 1k, 2k, 4k, 6.3k, 12kHz) ±10 dB / Q = 1.5 to 2.5
Filter
LO-CUT, mono inputs f = 80 Hz, 18 dB/oct.
Filter
LO-CUT, mono inputs f = 80 Hz, 18 dB/oct.
Display 128 x 64 pixels, OLED
Effects
Type Dual stereo 24/48-bit multi effects processors
Effects presets 100 Factory + 20 User, Tap-Delay
Remote control Footswitch, MIDI
Digital Audio Interface
Channels 4 In / 4 Out
AD/DA Conversion 24-bit
Sampling Rate 44.1 / 48 / 88.2 / 96 kHz
PC Interface USB2.0, Female Type B
Supported OS See documentation
MIDI Interface 5-pin DIN connector, In / Out
Protection
Mixer Outputs (Relay controlled) AUX, MON, MASTER A L/R
Switching Mode Power Supply (µC controlled) Mains Over/Undervoltage
Phantom Power, switchable 48 V DC
Power Requirements (SMPS with auto range mains input) 100 V to 240 V AC, 50 Hz to 60 Hz
Power Consumption, at 1/8 maximum output power, 4 Ω 35 W
Safety Class I
Ambient Temperature Limits +5 °C to +40 °C (40 °F to 105 °F)
Dimensions (W x H x D), mm 416.9 x 108.6 x 347.8 Rack-mount (7.5 HE): 483.0 x 99.1 x 332.6
Weight
Net Weight 5.8 kg
Shipping Weight 7.8 kg
Warranty 36 months
Optional Accessories
RMK-600-3 (Rack Mount Kit for CMS 600-3) F01U214881 (DC-RMK-CMS-3)
FS 11 (Footswitch with LED) F01U100598 (DC-FS11)
Carrying Bag for CMS 600-3 F01U259015 (DC-BAG-600CMS)
